For everyone with lots to do... and who likes some fun when done.
Name your chore and let the champ take over. For here is the most versatile and practical set of wheels going for answering a call, delivering an order, hauling a load, checking a fence, chasing a steer, or for simply getting you to a job site and back.
Folks are often flabbergasted at the many other things the International Scout can do. Things like operating a winch, snow plow, rotary sweeper, post hole auger, mower and lost of other attachments.
All this takes power. And Scout models have the right power for your purpose in a choice of three engines—two peppy fours or a high-spirited V-8. Moreover, they can be equipped with a three-speed or four-speed transmission, two-wheel drive, limited-slip differntial, and even right hand steering. The largest selection of performance options of any vehicle of its kind. Small wonder more work is done with Scout wheels than any other compact in the field.
For everyone who wants to break old habits and blaze new trails.
Shed the conventional and come alive with the all-wheel drive. In the Scout you can drive to where other have to walk. You can wheel down to the seashore or whip up into the mountains with equal ease. No road is too remote, no campsite, fishing hole or scenic spot too inaccessible with Scout traction at your command.
And with new V-8 power, you have pull-ability aplenty to tote boat and camper trailers through virtually any terrain.
Your new-found freedom can be expanded with extra equipment to broaden Scout cersatility and utility. Auxiliary gas tanks, increased-capacity cooling for 4-cylinder engines, heavy-duty electrical system, heavy-duty springs, axles, clutches, larger-size tires and rims—all are available on every model.
You also have an open season on interior conveniences and appointments. Prefer bucket seats and padded doors? Just say the word. The same goes for Deluxe all-vinyl upholstery, 8-track stereo tape player, pushbutton radio, fresh air heater-defroster, cigar lighter, and so forth.
Three engines that give you more than just "horses" under the hood.
Scout power is a far cry from the conventional. The international-built engines used in every Scout incorporate the stuff and stamina of their big brothers that power tough International trucks. Power ratings are in keeping with Scout size, use and tradition of economy. You get true, usable, high-torque horsepower geared to reach the wheels at most economical engine speeds. matched with either the standard three-speed or optional four-speed transmission, you have the most productive and reliable pwoer team going.
Top-Powered Valve-In-Head V-8
At right is the International high-torque V-8 available in all Scout body styles with all-wheel drive. This 155 hp, 266 cubic inch unit is equipped for real action with a large-capacity full-flow oil filter, oil bath air cleaner, a high-capacity cooling system for extra-strenuous driving conditions and a low-speed cut-in alternator to reduce battery drain.
Scout durability is built deep. It starts with a heavily reinforced welded steel box frame on a 100-inch wheelbase. Coupled with a firm multi-leaf front suspension system, it lets you enjoy an extraordinary sure-footed ride. Scout suspension keeps the nose up and out of trouble in rough terrain. It prevents a squishy, bucking sensation when traveling over ruts and hard roads. As a result, you constantly retain the feel of the vehicle and the road. Breakes have heavy-duty bonded linings.
A husky 3,500 pound capacity rear axle adds to overall strength. It absorbs stress and increases load-carrying ability. The chassis is topped off with a tight, welded body — carefully constructed and insulated against noise and vibration, and finished for excellent protection against weather and corrosion.
All told, the International Scout is built the way all off-the-road action vehicles should be — strong, stable and tight, with components that exceed conventional standards.
Every Scout model comes factory equipped with this complete safety package for greater security from driver's compartment to chassis:
Additional Standard Safeguards
Every Scout is also equipped with extra protection against rough terrain travel. Nothing hangs below the frame. The gas tank is fully enclosed and mounted outside the driver's compartment, above the frame. The radiator is protected in the front by a steel frame cross member, and underneath by a heavy steel flange.
The Internaitonal Scout gives you as standard equipment features that are either optional or not available on other vehicles of its type. In fact, the Scout doesn't skimp anywhere along the line.
Take its instrumentation. It's complete — a fully-instrumented padded sah including oil pressure and ammeter gauges. The windsheild is permanent, with bottom-mounted wipers to give you a full sweep and to keep water from splashing back and forth. Defroster vents run clear across, not just on the sides. The front passenger bucket seat tilts out of the way so other passengers can step, instead of climb, into the rear. And there's no gas tank to trip over. It's outside so there are no fumes or danger from spillage inside. All seats are thickly foam padded. Doors and roof are sound deadened. And the golve compartment is wide enough for a long flashlight and other sizeable items.
The Scout can be tailored to your preference in appearance as well as performance. Each body style is available with standard Utility or optional Custom interior and trim.
Standard Equipment
Offers all basic comfort and convenience features: full-width foam padded seat in durable vinyl, insulated rubber floor mat, ash tray, silver-gray front bumper, plus the complete safety package.
Custom Equipment
Enhances styling with a color-keyed interior equipped with either full-width or bucket front seats with all-vinyl Deluxe upholstery and matching padded door panels. Other refinements include dual arm rests, textured front floor mat, vinyl-covered acoustical headliner in steel TRAVELTOP, cigar lighter, chrome full-wheel discs, chrome inside and outside rear-view mirrors, and a chrome front bumper.
Popular Comfort and Convenience Accessories
Popular Comfort and Convenience Accessories
Choice of full-width or bucket seats with solid bulkhead or open access to the rear. Spare ties can be mounted inside or outside of the tailgate.
Equips TRAVEL-TOP body style as a four-passenger sedan. Also available for open Roadster. Foam-padded and upholstered in vinyl to match Custom front seat.
Seat four adults or more children. Lets you use TRAVEL-TOP style as a wagon for people or cargo. Five-foot long floor area is free for load space.
Two-tone combinations available at slight extra cost.
Weekday/Weekend Wagon!
It's the start of a new way of life. The most exciting blend of beauty and adventure ever to hit the road—Scout II.
Cruise along with the crowd. Then pull off the pavement for parts unknown whenever you feel the urge. For years, the International Scout has enjoyed the reputation as the "go-anywhere" vehicle. And now the all-new generation Scout II brings you stronger construction, more room, a wider choice of engines andmany other innovations to give you an even better getaway-from-it-all machinethan ever before. Acombination of features you can't find in any other American or foregin compact. Prove it to yourself with an exciting demonstration drive. It might be the start of a new way of life.
Your first glimpse of Scout II gives you a strong hint of what's to come. Completely restyled from front to rear, Scout II looks twice as sporty, coming or going. Or standing still.
Choose from seven exterior body colors, and four color-coordinated interior colors. Sit in the driver's seat. You'll notice the sweeping new dashboard that combines beauty and boldness with some sensible ideas (gauges instead of idiot lights and patded instrument panel).
Look for other fine touches, like winshield washers, roomy glove compartment, patded sun visors, adjustable window vents, and arm rests. And if you want even more glamour, order the deluxe exterior trim (shown) and deluxe or custom interior trim packages that atd distinctive extras.
Drive up to the country club in the morning for golf. Spend the afternoon cavorting across the boondocks. Then return in the evening for the big dance. Scout II belongs wherever you go. It's the most versatile "wagon" you can get. but watchout—you might find your Scout has become your "favorite car."
Every square inch of new Scout II has been space-engineered and put to work for you. The full-witdh rear seat gives passengers lots of room to spread out. And the luggage space in back will accommodate enough suitcases for a cross-country trip.
If you want atditional cargo area, you can fold down the rear seat. Presto—extra needed footage. Upfront more foor room—good news for long legs and long trips.. And more relaxation in thick foam-patded seats.
Your ride in the International Scout II is quieter too, thanks to improved engine mountings and extra insulation. You can have air conditioning to give you year-round comfort, and tinted glass all around.
Get the space you need in a fun machine. Step into the new Scout II. Settle back in solid comfort, no matter where you point your wheels.
You'll be impressed with Scout convenience the minute you open the door. The enterances are wider... doors open farther... let you enter and exit more easily. If you're getting in the wide rear seat, the backs of the front seats fold down for easy access. And you don't have to step over the door frame to get in Scout II. It's level with the floor—another major structural improvement!
Other conveniences you can get in your Scout II are power brakes and power steering. You'll also like the optional roof luggage rack, which atds beauty as well as utility. A few of the little convenience extras included in the deluxe interior trim package for the Traveltop model are cigarette lighter, rear dome light, courtesy lamp and coat hook, as well as color-keyed interior, spare tire cover, undercoating, and parking brake warning light.
If you want to combine convenience with adventure, jump in a luxurious Scout II and head for the hills.
Performance is the payoff in the new Scout II. It leaves all the other compacts behind in total capability.
Take the cab top model shown. Slip behind the wheel and see for yourself why you don't have to go to an import to get a compact pickup that's styled right, built right, powered right—and price right! You get American performance. A choice of four engines—from the spunky 111 hp, four-cyliinder Cpmanche up to a new 345 cubic inch, 197 hp V-8 that can even pull a 3,000 pound trailer load. You can have a three or four-speed manual transmission or an automatic three-speed. Plus four-wheel drive that lets you make your own road.
You get leaf springs at all four wheels. A drive train built to take tough loads and cross country jostling. High clearance combined with low center of gravity. Short front and rear overhang for greater maneuverability. Small wonder the Scout is the choice of so many commerical people, such as contractors, service station operators, ranchers and nursery men, as well as individualists who want to satisfy their wanderlust and roam at will.
The Scout II pickup also offers you a number of extra pulses, like a choice of two or four-wheel drive, limited slip differential, integral utility step bumper and trailer hitch, transfer case power take-off, skid plate, increased-capacity electrical system, bench or bucket seats and direct-reading, full-instrumented dash. All in atdition to traditional International quality and truck-tough construction.
| Traveltop or Cab Top | 4x2 | 4x4 |
|---|---|---|
| Wheelbase, Inches | 100 | 100 |
| Front Axle | FA-3 I Beam | FA-13 Driving Front Axle |
| Front Axle Capacity, Lbs. | 2,500 | 2,500 |
| Rear Axle Capacity, Lbs. | 3,500 | 3,500 |
| Rear Axle Ratios | 3.31, 3.73 or 4.27 to 1 | |
| Brakes, Hydraulic Optional | 11" x 2" Front and 11" x 1¾" Rear Power Brakes | |
| Fuel Tank Capacity | 19 Gallons with evaporative emission control system | |
| Engines |
4-196 111 HP Gasoline with exhaust emission control 6-258 150 HP Gasoline with exhaust emission control V-304 193.1 HP Gasoline with exhaust emission control V-345 196.7 HP Gasoline with exhaust emission control |
|
| Increased Cooling | Available on all Optional Engines (included in Air Conditioning Package) | |
| Clutch | 10: 6-Spring Standard with 4 Cylinder Engine | |
| Clutch for 6-258 Engine | 10½" | 10½" |
| Clutch for 4-196 Engine and V-304 Engines | 11" Angle Link Clutch 1,800 Lb. Plate Pressure | |
| Clutch for V-304 Engine and V-345 Engines | 11" Angle Link Clutch 2,000 Lb. Plate Pressure | |
| Transmissions |
3-Speed Floorboard Mounted Shift T-39 Automatic Transmission T-44 4-Speed Manual (4x2) Models Only T-45 4-Speed Manual (4x4) Models Only T-49 Automatic (for V-345 Engine Only) |
|
| Suspension, Front, Std., Lbs. |
2,200 Lb. All Models 40" x 2" 2,400 Lb. Heavy Duty Front Springs |
|
| Suspension, Rear, Std., Lbs. | 2,000 56" x 2" | 2,000 56" x 2" Rear Springs |
| Optional |
2,000 Lb. Heavy Duty Rear Springs 2,500 Lb. Heavy Duty Progressive Rear Springs |
|
| Optional Air-type, Leve-Ride Attachment | 4x4 Only | |
| Electrical System |
12 Volt 50 Amp. Hr. Battery 12 Volt 37 Amp. Alternator |
|
| Fresh Air Heater and Defroster | Standard all models | |
| Tires (Quantity 5) Std. |
E-78 x 15 PC 2 Ply LRB Tubless 5.50 K Rims F-78 x 15 PC 2 Ply LRB Tubless 5.50 K Rims G-78 x 15 PC 2 Ply LRB Tubless 5.50 K Rims H-78 x 15 PC 2 Ply LRB Tubless 5.50 K Rims Also Available in all traction tread, all sizes and white side walls. |
|
| Power Steering | Optional All LHD Models | |
| Heater and Air Conditioner Package | Includes 61 Amp. Alternator; 12 Volt 70 Amp. Hr. Batter, increased cooling | |
| Deluxe Interior Trim Package | Includes Color Keyed Interiors (Red, Blue, Sage and Black). Vinyl Door Trim Panels. Vinyl Color Keyed Floor Mats with Insulation. CIgar Lighter. Headliner and Rear Side Panels with Insulation (Traveltop). Rear Dome Light (Traveltop), Coat Hook (Traveltop), Courtesy Lamp. Parking Brake with Warning Light. ⅓-⅔ Vinyl-Nylon Seat Color Coded. Spare Tire Cover (Traveltop) and Undercoating. | |
| Custom Interior Trim Package | Includes All the Deluxe Package Plus Carpeting in Lieu of Vinyl Floor Mats, Tinted Glass, DUal Electric Horns, Cargo Area Mat with Insulation (Travetop). | |
| Bucket Seats or ⅓-⅔ Vinyl-Nylon Seat | Available in Standard, Deluxe and Custom interiors | |
| Deluxe Exterior Trim Package | Includes Bright Grille Moulding, Bright Tail Lamp Bezels, Bright Parking Light Bezels, Bright Door Glass Vent Window Frame, Bright Windshield Trim Moulding, Bright Side Trim Moulding, Bright Liftgate Glass Moulding (Traveltop), Bright Rear Quarter Window Moulding (Traveltop only), Dual Chrome Outside Rear View Mirrors, Chrome Front and Rear Bumpers (Front only with Cab Top), Stainless Steel Wheel Covers. | |
It has what it takes to get you there.
America's a big country. And much of it is hard to reach in an orignary vehicle. So jump into a Scout II and scout the America you've been missing too long. High, winding mountain side roads. White water. Brawling rivers. Clean, sparkling lakes. Desert country.
Tough, durable, maneuverable, Scout has the raw power and stamina to take you almost anywhere you want to go. Easily. Comfortably. Safely. You could say it's your "freedom machine."
The tougher the going, the more you'll appreciate Scout II's exclusive dash-mounted 4-wheel drive engagement knob or optional lever-controlled two-speed transfer case. Optional automaic locking hubs mean you don't have to get out in the mud, rain or snow to get 4-wheelin'.
We know what you want in a 4-wheel drive machine. A rugged, durabe, gutsy, solid performer that can stand up to the toughest kind of off-road driving conditions. And Scout II gives it to you. Percision engineered, it has a body that's all-steel welded construction, powerful disc brakes in front that maintain straight-line control during heavy braking, self-adjusting drums in the rear, and a choice of three hard-charing gasoline engines or an economical diesel. A big 11-inch clutch and an easy-to-read functional instrument center are standard.
For protection against weather and chemicals in the air, the body of each Scout II goes through a very special rust prevention primer process. New electrostaic spraying techniques allow for smooth, even pain coverage.
Why do we put so much into Scout II? So you can demand more of it, and get it.
New electronic ignition system means quick starts and longer periods between tuneups. Eliminates breaker points and condenser; prolongs spark plug life.
Double-panel hood gives greater rigidity.
Short hood provides excellent road visibility. Open from the rear for safety and easy engine access.
The lockable and collapsible steering column helps prevent theft and increases safety in case of collision.
Direct-reading gauges include: temperature, ammeter, speedometer, oil pressure and fuel. All located in front of driver for easy visibility.
Optional seven-position steering wheel allows easy enterance and exit and adjusts for personal driving comfort.
100 in. wheelbase means great off-the-road mobility and maneuverability.
Dash-mounted courtesy lights.
Optional second seat provides rear passengers with a maximum of 33.4 in. leg room.
Sturdy steel roof is removable
Specious cargo area is 60.8 in. long and 54.8 in. wide. Has 82 cu. ft. capcity. With the tailgate open, you have a large 40 in. x 54.8 in. rear opening for convenient loading.
Increased cooling for optimum engine operating temeratures under all condtions is standard.
Short 33 ft. 10 in. turning diameter gets you out of tight spots safely.
Long leaf springs with six leaves front, four leaves rear, providing a 6200 lb. gross vehicle weight rating.
Locking hubs standard on 4x4 models.
Standard power disc front brakes for fade-resistant, sure braking under all conditons.
Rugged full-length steel box frame for strength and rigidity
Three-pass aluminized muffler for quiet operation and durability
46.5 in. wide doors make it easy to get in and out.
CHoice of engines: economical Comanche 4-cylinder 196, Comanche 304 cu. in V-8 or the big 345 cu. in. V-8. Operate on lead-free low-lead or regular fuel.
Easily accessible spare tire is mounted so that it doesn't restrict use of cargo area or rear visibility.
Optional sliding side windows for better rear seat ventilation.
All-steel fuel tank has 19-gallon capacity.
Quick-release latch permits optional second seat to fold neatly for maximum cargo space.
Rust-resistant, sound-deadening undercoating is standard.
It makes getting there half the fun.
When you're driving all day in the boonies, you'll appreciate Scout comfort. Whether you select the standard interior, the impressive deluxe, or the luxurious custom, you'll go in style. Choose from five easy-on-the-eyes interior trims and good-looking, easy-care, all-vinyl upholstery or handsome, long lasting vinyl/nylon upholstery. Standard bench seats and optional bucket seats have firm, deep-foam cushioning.
Even the standard interior is equipped with a fully instrumented dash, tinted glass, full front seat, courtesy lights, big glove compartment, color-keyed vinyl floormats, and padded sun cisors and armrests.
Whatever interior you pick, you'll find out that getting there is half the fun. Suddenly, it's fun to drive again.
Man or woman, you want a Scout that fits your lifestyle. The way you work. And play. The places you've always wanted to go, the things you've always wanted to do. We've got the options to make a Scout just right for you. Take a look at the list of options on the left. Then choose the ones that'll give you more comfort, fun and versatility. Scout options. They'll help you get more out of life.
Automatic locking hubs. They'll get you 4-wheeling without getting out in the weather.
Three-speed automatic transmission. Smooth, efficient three-speed automatic transmission lets you lean back and enjoy the ride.
Air conditioning. Keep your cool with Scout's air conditioning package. It includes a 390 CCA 12-volt battery and 61-amp alternator, and variable temperature and fan control.
AM/FM radios. CHoose your sound system from a variet of factory installed AM or AM/FM radios. And you Scout dealer can install a great sounding 8-track stereo tape player.
Cruise control. Sit back and relax while fuel-efficient cruise control with resume-speed feature takes over on those long highway stretches.
Luggage rack. Although you can haul a big load inside, the chrome luggage rack with adjustable crossbars lets you carry some more on the outside.
Sliding rear quarter windows. Open the sliding side windows and cool off naturally.
Heavy-duty rear step bumper. Tow up to 2000 lbs. smoothly and easily. And the step bumper makes it a cinch to load up the luggage rack.
10-15 LT LRB tires. These big, rugged tires deliver superb traction on the toughest kind of off-road situations.
Seven-position tilt steering wheel. Adjustable so a driver can select a comfortable position; easier to enter and exit.
If you weren't a special kind of person, you wouldn't be driving a Scout. We know that, so we paint Scout with colors that say action, color, excitement. Nine vibrant colors that are close to nature. And a selection of five sport appliques to personalize it. You're never just part of the crowd in a Scout. You're above it.
| Comanche 4-196 | Comanche V-8 304A | V-8 345A | |
|---|---|---|---|
| Displacement (cu. in.) | 196 | 304 | 345 |
| Bore & Stroke (in.) | 4⅛-321/32 | 3⅞-37/32 | 3⅞-321/32 |
| Compression Ratio | 8.02 to 1 | 8.19 to 1 | 8.05 to 1 |
| SAE Net Horsepower* @ r.p.m. | 86 @ 3,800 | 144 @ 3,600 | 163 @ 3,600 |
| SAE Net Torque* @ r.p.m. | 157 @ 2,200 | 247 @ 2,400 | 292 @ 2,000 |
| SAE Net Horsepower** @ r.p.m. | 79 @ 3,600 | N/A | 138.5 @ 3,400 |
| SAE Net Torque** @ r.p.m. | 155 @ 2,000 | N/A | 271 @ 2,000 |
| *For all state except California **California Only |
|||
| Engine | Transmission | Axle Ratios | |
|---|---|---|---|
| Standard | Optional | ||
| Comanche 4-Cylinder: 4-196 | |||
| 3-Speed Manual Fully Synchronized (Standard) |
4.09 | ||
| 4-Speed Manual Fully Synchronized Wide Ratio (4x4 Models Only) |
4.09 | 3.54 3.73 | |
| 4-Speed Manual Fully Synchronized Close Ratio |
3.54 | 3.73 4.09 |
|
| 3-Speed Automatic | |||
| V-8's: V-304 & V-345 | |||
| 3-Speed Manual Fully Synchronized (Standard) |
3.54 | 3.73 4.09 w/ V-304 Only |
|
| 4-Speed Manual Fully Synchronized Wide Ratio (4x4 Models Only) |
3.54 | 3.73 4.09 w/ V-304 Only |
|
| 4-Speed Manual Fully Synchronized Close Ratio |
3.07 | 3.54 3.73 4.09 w/ V-304 only |
|
| 3-Speed Automatic | |||
| Standard | Optional | ||
|---|---|---|---|
| GVW Rating (lb.) | 6,200 | ||
| Clutch | 11" Angle Link | 11" Angle Link H.D. | |
| Front Suspension | Axle Type/Cap. (lb.) | 4x2 FA-3 Rubular Steel/3100 4x4 FA-44 Driving Hypoid/3200 |
|
| Springs Type/Cap. (lb.) | Leaf/3100 | H.D. Leaf/3200 | |
| Shock Absorbers | 1" Diam. | 13/16" Diam H.D. | |
| Stabalizer Bar | Front | ||
| Rear Suspension | Axle Type/Cap. (lb.) | Semifloating/3500 | Semifloating w/ Trac-Lok/3500 |
| Springs Type/Cap. (lb.) | Leaf/3100 | H.D. Progressive Leaf/3100 | |
| Shock Absorbers | 1" Diam. | 13/16" Diam H.D. | |
| Brakes | Front/Rear | Power Disc/Drum | |
| Electrical | Battery CCA | 300 | 390 or 500 |
| Alternator (amp.) | 37 | 61 | |
| Fuel Tank | Nominal Capacity (gal.) | 19 | |
| Steering | Type | Manual | Integral Power |
| Transfer Case | Single Speed "Silent Drive" |
2-Speed Gear Drive |
|
| Tires | Tubeless | H78x15 LRB |
H78x15 LRB WSW H78x15 LRB Mud/Snow H78x15 LRB Mud/Snow WSW H78x15 LRB Radial WSW 10-15 LT LRB On-Off Hi-way White Letter |
| Tube Type | 700x15 LRC Regular Tread 700x15 LRC Mud/Snow |
||
| Class | I | II | III |
|---|---|---|---|
| Loaded Trailer Weight | Up to 2,000 lb. | 2,000 lb. to 3,500 lb. | 3,500 lb. to 5,000 lb. |
| Max. Gross Combined Weight | 6,700 lb. | 8,200 lb. | 10,000 lb. |
| Trailer Hitch Type | H.D. Step Bumper | Equalizer Type | Equalizer Type |
| Max. Tongue Load | 300 lb. | 15% of Gross Trailer Weight | 15% of Gross Trailer Weight |
| Transmission (Automatic) | T-407 | T-407 | T-407 |
| Transmission (Manual) | T-332, 3-Speed w/ Heavy Duty Clutch | T-428 Close Ratio, 4-Speed w/ Heavy Duty Clutch | T-428 Close Ratio, 4-Speed w/ Heavy Duty Clutch |
| Tires | H78x15 LRB Standard | H78x15 LRB Standard | H78x15 LRB Radial |
| Battery | 300 CCA Standard | 390 CCA w/ Towing Package | 390 CCA w/ Towing Package |
| Alternator 6-Way Wiring | 37 amp. Recommended | 61 amp. w/ Towing Package | 61 amp. w/ Towing Package |
| Heavy-Duty Closed Cooling System | Standard | Standard | Standard |
| Power Disc Brakes | Standard | Standard | Standard |
| Power Steering | Not Required | Recommended | Recommended |
| Engine | Total Combined Weight, lb, | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|
| 6,200 | 7,000 | 8,000 | 9,000 | 10,000 | ||||||
| V304 | 3.07 | 3.54 | 3.73 | 4.09 | N.R. | |||||
| V345 | 3.07 | 3.54 | 3.73 | |||||||
